Red 3


Material:  Aluminium
Measuring tolerance standard position: 0.30 mm/m (0.017°)
Measuring tolerance inverted measurement: 0.50 mm/m (0.029°)

Model Length
RED 3 60 60 cm
RED 3 80 80 cm
RED 3 100 100 cm


  • Highest measuring accuracy in standard and inverted position
  • Extra strong aluminium profile with reinforcing ribs for maximum stability
  • Better, faster and more accurate reading through the patented SOLA FOCUS vials
  • Break-resistant acrylic block vials with magnifying lens (+60%) and a 30 year guarantee against leakage
  • Better readability in dim light through an optimised SOLA luminous backing
  • Shock-absorbing 2-c end caps provide optimum protection against damage


  • Horizontal measurement
  • Vertical measurement


Item description Box profile spirit level
Dimension 59 x 27
Material Aluminium
Surface epoxy coated
Colour red
Profile weight 890 g/m
Measuring tolerance standard position 0.30 mm/m (0.017°)
Measuring tolerance inverted measurement 0.50 mm/m (0.029°)
Number of horizontal vials 1
Number of vertical vials 2
Measuring surface epoxy coated
End caps 2-c
