CHARACTERISTICS
Material: Aluminium
Measuring tolerance standard position: 0.50 mm/m (0.029°)
Measuring tolerance inverted measurement: 1.00 mm/m (0.057°)
Measuring tolerance standard position: 0.50 mm/m (0.029°)
Measuring tolerance inverted measurement: 1.00 mm/m (0.057°)
| Model | Length |
| AV 30 | 30 cm |
| AV 40 | 40 cm |
| AV 50 | 50 cm |
| AV 60 | 60 cm |
| AV 80 | 80 cm |
| AV 100 | 100 cm |
| AV 120 | 120 cm |
| AV 150 | 150 cm |
| AV 180 | 180 cm |
| AV 200 | 200 cm |
| All prices are non-binding recommendations. Prices incl. statutory VAT. | |
CHARACTERISTICS
- High measuring accuracy in standard and inverted position
- Robust aluminium profile
- Better, faster and more accurate reading through the patented SOLA FOCUS vials
- Break-resistant acrylic block vials with a magnifying lens (+20%), and a tightness guarantee of 30 years
- Better readability in dim light through an optimised SOLA luminous backing
- Shock-absorbing end caps
APPLICATIONS
- Horizontal measurement
- Vertical measurement
TECHNICAL DETAILS
| AV | |
| Item description | Box profile spirit level |
| Dimension | 49 x 21 mm |
| Material | Aluminium |
| Surface | anodized |
| Colour | silver |
| Profile weight | 520 g/m |
| Measuring tolerance standard position | 0.50 mm/m (0.029°) |
| Measuring tolerance inverted measurement | 1.00 mm/m (0.057°) |
| Number of horizontal vials | 1 |
| Number of vertical vials | 1 |
| Measuring surface | anodized |
| End caps | 1-c |
